High-Precision Battery Voltage Internal Resistance Tester, Specifications: Host+Clamp

High-Precision Battery Voltage Internal Resistance Tester measures battery voltage and internal resistance. It is suitable for various battery production, maintenance, and testing scenarios.

• Product Type: Battery & Resistance Tester
• Compatibility: Various batteries
• Key Feature: High precision measurement
• Speed: 5 tests per second
• Resistance Measurement Range: 1μΩ to 200Ω
• Voltage Measurement Range: 1mV to 100V DC
• Test Signal Frequency: AC 1kHz
• Test Signal Current: 20mΩ at 50mA; 200mΩ at 5mA; 20Ω at 0.5mA
• Resistance Range: 6 ranges, automatic and manual
• Voltage Range: 3 ranges, automatic and manual
• Display Update Rate: 5 times per second
• Language: Chinese and English switchable
• Additional Functions: Measures AC resistance and low resistance of capacitors
• Power Source: Built-in 1000mAh lithium battery
• Size: 80mm x 171mm
• Design Features: Intelligent control, LCD display, Kalman filter algorithm for accuracy
• Measurement Method: Four-wire test clip to minimize contact and wire resistance effects
• Applications: Battery production, maintenance, testing, scientific research laboratories
